Design Phase in SDLC: Key Activities, Types & Examples

By Abhay Talreja

10/28/2025

My latest article - Empirical Process Control - The Key to Agile Success

The Design Phase in SDLC is the critical stage where software requirements are transformed into detailed technical specifications and architectural blueprints.

This phase creates comprehensive design documents - including High-Level Design (HLD), Low-Level Design (LLD), UI/UX designs, database schemas, and system architecture - that guide developers in building the actual software product.

Key characteristics: The design phase begins after requirements analysis and produces deliverables like Software Requirement Specification (SRS) documents, wireframes, prototypes, and technical design documents.

It involves crucial activities such as architectural design, database design, interface design, and risk analysis before any coding begins.

Quick Answer: Design Phase at a Glance

This article provides a comprehensive guide to the design phase in Software Development Life Cycle (SDLC), covering key activities, design types, deliverables, roles, and best practices with real-world examples.

What is the Design Phase in Software Development?

The design phase in SDLC is the critical bridge between requirements analysis and actual software development. It transforms business requirements and functional specifications into detailed technical blueprints that developers can follow to build the software product.

During this phase, technical architects, designers, and engineers create comprehensive design documents that specify how the system will work, not just what it should do. This includes system architecture, database schemas, user interfaces, module interactions, and technical implementation strategies.

The design phase produces tangible artifacts such as architectural diagrams, wireframes, prototypes, database models, and detailed technical specifications that serve as the construction blueprint for the development team.

All design artifacts are compiled into a Software Requirement Specification (SRS) document and Design Document Specification (DDS), which undergo stakeholder review and approval before the development phase begins.

Key Activities in the Design Phase (What is Crucial)

The design phase encompasses several crucial activities that transform requirements into implementable specifications. Understanding which activities are most critical helps teams prioritize efforts and ensure comprehensive design coverage.

1. Architectural Design

Architectural design is the most crucial activity in the design phase, as it establishes the fundamental structure and technology foundation of the entire system.

Key Components:

• System Architecture: Define the overall structure using patterns like microservices, monolithic, client-server, or layered architecture
• Technology Stack Selection: Choose programming languages, frameworks, databases, and infrastructure based on requirements and constraints
• Component Identification: Break down the system into manageable modules, services, and components
• Integration Strategy: Plan how different components, third-party services, and existing systems will interact
• Scalability Planning: Design for future growth in users, data volume, and feature expansion

Deliverables: System architecture diagrams, technology stack documentation, component interaction diagrams

2. User Interface (UI) and User Experience (UX) Design

UI/UX design ensures the software is intuitive, accessible, and meets user expectations for usability and aesthetics.

Key Activities:

• User Journey Mapping: Document how users will navigate through the application
• Wireframing: Create low-fidelity layouts of screens and interfaces
• Prototyping: Build interactive mockups for user testing and stakeholder validation
• Visual Design: Define color schemes, typography, iconography, and branding elements
• Accessibility Planning: Ensure designs comply with WCAG standards and accommodate diverse users

Deliverables: Wireframes, interactive prototypes, style guides, UI component libraries

3. Database Design

Database design structures how data will be stored, retrieved, and managed throughout the system lifecycle.

Key Activities:

• Data Modeling: Create Entity-Relationship Diagrams (ERD) showing tables, relationships, and cardinality
• Schema Design: Define table structures, columns, data types, and constraints
• Normalization: Organize data to reduce redundancy and improve integrity
• Indexing Strategy: Plan indexes for optimal query performance
• Data Migration Planning: Design strategies for importing existing data

Deliverables: ER diagrams, database schema documents, data dictionary, migration scripts

4. Technical Specification Creation

Technical specifications provide detailed implementation guidance for every component and module.

Key Activities:

• Module Specifications: Document functionality, inputs, outputs, and logic for each module
• API Design: Define endpoints, request/response formats, authentication, and error handling
• Coding Standards: Establish naming conventions, code structure, and quality guidelines
• Interface Specifications: Detail how components communicate with each other
• Algorithm Design: Plan complex algorithms and business logic implementation

Deliverables: Technical design documents, API specifications, coding standards documentation

5. Risk Analysis and Mitigation

Risk analysis identifies potential technical, security, and operational risks before implementation begins.

Key Activities:

• Security Risk Assessment: Identify vulnerabilities and plan security measures
• Performance Risk Analysis: Anticipate scalability and performance bottlenecks
• Integration Risk Evaluation: Assess challenges with third-party integrations
• Technology Risk Review: Evaluate risks with chosen technologies and frameworks
• Mitigation Strategy Development: Create contingency plans for identified risks

Deliverables: Risk register, security assessment report, mitigation strategy documents

6. Quality Verification and Validation

Quality activities ensure designs meet requirements and are feasible for implementation.

Key Activities:

• Design Reviews: Conduct peer reviews of architectural and technical designs
• Feasibility Validation: Verify that designs can be implemented within constraints
• Requirement Traceability: Ensure all requirements are addressed in design
• Prototype Testing: Validate designs with stakeholders and end users
• Quality Gate Checks: Ensure design meets organizational quality standards

Deliverables: Design review reports, validation checklists, prototype feedback documentation

Which Activity is Most Crucial? While all activities are important, architectural design is the most crucial because it establishes the foundation upon which all other design decisions are built. A flawed architecture is difficult and expensive to fix later, while UI, database, and other designs can be refined during development.

Types of Design: High-Level Design (HLD) vs Low-Level Design (LLD)

The design phase is typically divided into two complementary levels of abstraction: High-Level Design (HLD) and Low-Level Design (LLD). Understanding both is essential for comprehensive system design.

High-Level Design (HLD)

High-Level Design provides the big picture of the system architecture without delving into detailed implementation specifics. It focuses on the overall system structure and how major components interact.

HLD Components:

• System Architecture Overview: Bird's-eye view of the entire system structure
• Major Modules and Components: Identification of primary functional blocks
• Module Relationships: How different modules communicate and depend on each other
• Technology Stack: High-level technology decisions (database type, programming languages, frameworks)
• External Interfaces: Integration points with third-party systems and APIs
• Data Flow Diagrams: How data moves through the system at a macro level
• Infrastructure Architecture: Server architecture, cloud services, deployment topology

HLD Characteristics:

HLD Example Components for E-commerce System:

• Frontend Layer (Web + Mobile)
• Backend API Layer
• Business Logic Layer
• Data Access Layer
• Database (SQL + NoSQL)
• Payment Gateway Integration
• Notification Service
• Search Service

Low-Level Design (LLD)

Low-Level Design provides the detailed blueprint for implementing each component identified in the HLD. It specifies exactly how developers should build each module.

LLD Components:

• Detailed Module Specifications: Complete functional description of each module
• Class Diagrams: Object-oriented design with classes, attributes, and methods
• Database Schema: Detailed table structures, columns, data types, constraints, indexes
• Algorithm Specifications: Pseudocode or flowcharts for complex logic
• Interface Details: Exact API endpoints, request/response formats, error codes
• Data Structures: Specific data structures to be used in implementation
• Error Handling Logic: Detailed exception handling and recovery mechanisms
• Security Implementation: Specific security measures for each component

LLD Characteristics:

HLD vs LLD Comparison:

Design Phase Deliverables

The design phase produces comprehensive documentation and artifacts that guide the development team. Here are the key deliverables:

Primary Deliverables:

1. Software Requirement Specification (SRS) Document: Approved and refined requirements with design context
2. High-Level Design (HLD) Document: System architecture, component diagrams, technology stack
3. Low-Level Design (LLD) Document: Detailed module specifications, algorithms, data structures
4. Database Design Document: ER diagrams, schema definitions, data dictionary
5. UI/UX Design Artifacts: Wireframes, mockups, prototypes, style guides
6. API Specifications: Endpoint definitions, request/response formats, authentication
7. Architecture Diagrams: System architecture, deployment architecture, network topology
8. Technical Specifications: Coding standards, naming conventions, development guidelines

Supporting Deliverables:

• Design review reports
• Risk assessment documents
• Security design specifications
• Performance requirements and benchmarks
• Test strategy based on design
• Interface specifications
• Data migration plans
• Technology evaluation reports

Why the Design Phase is Important in Software Development

Good design serves as the backbone of efficient, scalable, and sustainable software.

Leveraging time at this phase for careful design ensures easier updates and maintenance while reducing the risks of technical debt.

Investing time upfront in designing your software allows for easier updates and maintenance, and minimizes the risks associated with legacy software and technical debt.

This future-proofed design ensures the software maintains high performance and reliability in an ever-evolving digital environment.

For your final software product to align with your original vision, it's crucial to delineate and scrutinize your requirements thoroughly.

The key undertakings in the design phase of SDLC encompass User Interface (UI) design review, technical design formulation, and quality authentication.

Roles and Responsibilities in the Design Phase

The design phase involves various stakeholders, each with distinct roles and responsibilities. Clear role definition ensures comprehensive design coverage and smooth collaboration.

Design Phase Examples: Real-World Scenarios

Understanding design phase activities through real-world examples helps clarify abstract concepts. Here are three comprehensive examples across different domains.

Example 1: E-commerce Platform Design

Project Context: A mid-sized retailer wants to build a new e-commerce platform to compete with online giants.

Requirements Summary: Online product catalog, shopping cart, secure checkout, order management, inventory integration, customer accounts, recommendation engine.

Design Phase Activities:

1. Architectural Design:

• HLD: Microservices architecture with separate services for catalog, cart, checkout, user management, and recommendations
• Technology Stack: React (frontend), Node.js (backend), PostgreSQL (transactional data), MongoDB (product catalog), Redis (caching), AWS (infrastructure)
• Integration Points: Payment gateway (Stripe), shipping API (FedEx/UPS), existing ERP system

2. Database Design:

• Users Table: user_id, email, password_hash, name, address, created_at
• Products Table: product_id, name, description, price, inventory_count, category_id
• Orders Table: order_id, user_id, total_amount, status, order_date, shipping_address
• Order_Items Table: order_item_id, order_id, product_id, quantity, price

3. UI/UX Design:

• Wireframes: Homepage with featured products, product listing pages, product detail pages, shopping cart, checkout flow
• Prototypes: Interactive prototype demonstrating complete purchase flow from browsing to order confirmation
• Mobile-First Design: Responsive design prioritizing mobile experience

4. API Design:

GET /api/products - List products with filters
GET /api/products/{id} - Get product details
POST /api/cart/add - Add item to cart
POST /api/orders - Create new order
GET /api/orders/{id} - Get order details

Design Deliverables:

• HLD document with microservices architecture diagram
• Database ER diagram with 15+ tables
• 50+ wireframes and 5 interactive prototypes
• API specification with 30+ endpoints
• Security design including PCI compliance for payments

Example 2: Mobile Banking Application Design

Project Context: A regional bank needs a mobile app for customers to manage accounts, transfer money, pay bills, and apply for loans.

Requirements Summary: Account balance viewing, fund transfers, bill payments, check deposit, loan applications, biometric authentication, real-time notifications.

Design Phase Activities:

1. Architectural Design:

• HLD: Native mobile apps (iOS/Android) + RESTful API backend + Core banking system integration
• Technology Stack: Swift (iOS), Kotlin (Android), Java Spring Boot (backend), Oracle DB (banking data), Firebase (notifications)
• Security Architecture: Multi-layer security with biometric auth, device binding, transaction signing, encryption at rest and in transit

2. Security-First Design:

• Authentication: Biometric (Face ID/Fingerprint) + PIN + Device registration
• Authorization: Role-based access control with transaction limits
• Encryption: AES-256 for data at rest, TLS 1.3 for data in transit
• Fraud Detection: Real-time transaction monitoring, unusual activity alerts

3. UI/UX Design Considerations:

• Accessibility: WCAG 2.1 AA compliance, screen reader support, high contrast mode
• Simple Navigation: Bottom tab bar with 5 main sections (Home, Accounts, Pay, Services, Profile)
• Quick Actions: Dashboard with quick access to common tasks (Check Balance, Transfer Money, Pay Bill)

4. Offline Capability Design:

• Local Data Caching: Cache account balances and recent transactions for offline viewing
• Queue Management: Queue offline transactions for execution when online
• Sync Strategy: Background sync when connectivity restored

Design Deliverables:

• Mobile app architecture with offline-first strategy
• Security design document with threat modeling
• UI kit with 100+ components following platform guidelines
• Integration specifications for core banking APIs
• Comprehensive test plan including security testing

Example 3: Healthcare Management System Design

Project Context: A hospital network needs an integrated system for patient records, appointment scheduling, billing, and clinical workflows.

Requirements Summary: Electronic Health Records (EHR), appointment management, billing and insurance claims, clinical decision support, HIPAA compliance, interoperability with external systems.

Design Phase Activities:

1. Compliance-Driven Architecture:

• HLD: HIPAA-compliant architecture with audit logging, access controls, and data encryption
• Technology Stack: Angular (frontend), .NET Core (backend), SQL Server (primary database), HL7 FHIR (interoperability standard)
• Deployment: On-premises with private cloud backup for data sovereignty

2. Database Design with PHI Protection:

• Patient Table: Encrypted patient demographics and contact information
• Medical_Records Table: Clinical notes, diagnoses, treatment plans with field-level encryption
• Audit_Log Table: Comprehensive logging of all PHI access with timestamps and user IDs
• Appointment Table: Scheduling data with patient references

3. Role-Based Access Control (RBAC):

• Physicians: Full access to assigned patients' medical records
• Nurses: Read access to medical records, update vital signs and nursing notes
• Front Desk: Appointment scheduling, patient demographics, limited record access
• Billing Staff: Billing information, insurance details, no access to clinical notes
• Administrators: System configuration, user management, audit log review

4. Integration and Interoperability:

• HL7 v2 Interface: Integrate with existing laboratory and radiology systems
• FHIR API: Enable data exchange with external healthcare providers
• Insurance Eligibility Check: Real-time verification with major insurance providers
• E-Prescription: Integration with pharmacy networks for electronic prescriptions

Design Deliverables:

• HIPAA-compliant system architecture with security controls
• Detailed RBAC matrix with 10+ roles and 100+ permissions
• HL7/FHIR integration specifications
• Audit and compliance documentation
• Disaster recovery and business continuity plan

Transforming Requirements into System Design

The design phase involves converting the requirements into a system design, which takes place by creating a high-level design document and assessing its functional feasibility.

Scope and Impacted Modules

An in-depth understanding of the scope of your application is necessary, derived from analyzing the high-level and functional design. Also, it is crucial to identify the impacted modules and the level of impact on each module.

Integration and Technical Details

The design phase involves considering the integration of various modules or components in your software. After covering all the functional components, you move on to the technical details where tool and software selection takes place.

Risk Analysis and Technologies

For every decision made, from tool selection to organization, risks need to be evaluated for each option. The technical language used also needs careful selection based on the requirements.

Capability and Constraints

Complete understanding about the chosen system's or product's constraints are necessary. Also, a case study must be done around capability or proof of concept before picking technologies.

Time & Budget Considerations

Throughout the software development life cycle, time and budget aspects need close monitoring. This would consider the solution's urgency, the required resources, and the cost/budget for the resources you picked.

Time Allocation Guidelines:

• HLD Creation: 20-30% of design phase time
• LLD Development: 35-45% of design phase time
• UI/UX Design: 15-25% of design phase time
• Reviews and Approvals: 10-15% of design phase time
• Documentation: 5-10% of design phase time

Budget Considerations:

• Design phase typically consumes 15-25% of total project budget
• More complex systems may require up to 30% of budget for comprehensive design
• Investing more in design reduces development and maintenance costs
• Cost of fixing design flaws increases 10x during development, 100x in production

Design Phase Best Practices

Following established best practices ensures your design phase delivers high-quality, implementable specifications that guide successful development.

1. Start with Requirements Traceability

• Map every design element back to specific requirements
• Ensure no requirements are missed in the design
• Use traceability matrices to track requirement-to-design relationships
• Validate with stakeholders that all needs are addressed

2. Design for Scalability and Performance

• Consider future growth in users, data, and features
• Plan for horizontal and vertical scaling strategies
• Identify potential performance bottlenecks early
• Design with cloud-native principles when applicable

3. Prioritize Security by Design

• Incorporate security from the beginning, not as an afterthought
• Follow principle of least privilege for access control
• Plan for data encryption at rest and in transit
• Conduct threat modeling for critical components
• Design comprehensive audit logging

4. Create Modular and Maintainable Designs

• Apply SOLID principles for object-oriented design
• Use established design patterns (MVC, Microservices, etc.)
• Minimize coupling between components
• Maximize cohesion within modules
• Plan for easy testing and debugging

5. Involve Stakeholders Throughout

• Schedule regular design review sessions
• Present designs in stakeholder-appropriate formats
• Gather and incorporate feedback iteratively
• Get formal sign-offs before proceeding to development
• Maintain open communication channels

6. Document Thoroughly but Pragmatically

• Create comprehensive but concise documentation
• Use diagrams and visualizations effectively
• Maintain living documents that evolve with the design
• Ensure documentation is accessible to all team members
• Balance detail with readability

7. Validate Technical Feasibility

• Build proof-of-concept (POC) for risky technologies
• Validate performance assumptions with prototypes
• Test integration points with mockups
• Conduct technical spikes for uncertain areas
• Get feedback from development team on implementability

8. Plan for Testing from Design Phase

• Design systems that are testable
• Create test strategy alongside system design
• Identify test data requirements early
• Plan for unit, integration, and system testing
• Consider automated testing requirements

9. Consider Operational Requirements

• Design for monitoring and observability
• Plan deployment and rollback strategies
• Consider disaster recovery and business continuity
• Design for maintainability and supportability
• Include operational runbooks in design documentation

10. Use Design Tools and Standards

• Leverage UML, ERD, and other standard notations
• Use design tools (Figma, Lucidchart, Draw.io) for consistency
• Follow organizational design standards and templates
• Maintain version control for design documents
• Use collaborative platforms for team design work

Conclusion

The design phase of the Software Development Life Cycle (SDLC) is the critical bridge between conceptual requirements and concrete implementation. It transforms abstract business needs into detailed technical specifications that guide development teams in building software products.

Key Takeaways:

• Critical Activities: Architectural design, UI/UX design, database design, technical specifications, and risk analysis are the core activities, with architectural design being the most crucial
• Two-Level Approach: High-Level Design (HLD) provides the system overview, while Low-Level Design (LLD) specifies implementation details
• Comprehensive Deliverables: The design phase produces HLD/LLD documents, wireframes, prototypes, database schemas, API specifications, and technical documentation
• Cross-Functional Collaboration: Success requires active participation from architects, designers, developers, QA, security specialists, and stakeholders
• Investment Pays Off: Spending 15-25% of project time and budget on design reduces development costs and defects significantly

Success Factors:

The design phase succeeds when it balances thoroughness with pragmatism, involves all stakeholders, validates technical feasibility, and produces clear, implementable specifications.

Teams that invest adequately in design - following best practices for modularity, security, scalability, and documentation - build software that is more maintainable, reliable, and aligned with business objectives.

Next Steps:

After design phase completion and stakeholder approval, the project advances to the development/implementation phase, where developers transform design specifications into working code following the blueprints created during design.

The design phase is not just documentation - it's strategic thinking, technical planning, risk mitigation, and collaborative problem-solving that sets the foundation for successful software delivery.

Presentation used in the video

Here is the presentation slide used in the video. If you have any feedback, do let us know on our EasyRetro board. (opens in a new tab)

Frequently Asked Questions (FAQs) / People Also Ask (PAA)

Continue Reading
